The Transistor: The Invention That Made Everything Else Possible

The Problem with Glass

By the mid-1940s, electronic computers existed, but they were monsters. The ENIAC, completed in 1945, used nearly 18,000 vacuum tubes and occupied an entire floor of the Moore School of Electrical Engineering at the University of Pennsylvania. It consumed 150 kilowatts of power, generated enough heat to warm a house, and failed roughly every two days when one of its thousands of tubes burned out. Engineers spent more time replacing tubes than doing calculations.

The vacuum tube was a triumph of 1910s engineering that had reached its fundamental limits. It worked by heating a metal filament inside a glass envelope until electrons boiled off and could be steered by an electric field — exactly the same principle as an incandescent light bulb, just harnessed for switching and amplification rather than illumination. But heating filaments took time and energy. Glass envelopes broke. Tubes that ran hot enough to work reliably also wore out quickly.

The engineers who designed ENIAC understood perfectly that vacuum tubes were a dead end. What nobody knew was what would replace them. See From Vacuum Tubes to Transistors for the broader context of this transition.

Bell Labs and the Solid-State Group

In 1945, Mervin Kelly, research director at Bell Telephone Laboratories in Murray Hill, New Jersey, assembled a team to investigate solid-state alternatives to the vacuum tube. Bell Labs had both the motive and the means: AT&T’s telephone network depended on millions of vacuum-tube amplifiers in its long-distance lines, and every tube that failed required a technician. A solid-state amplifier with no moving parts, no filament, and no glass envelope would transform the economics of the entire telephone system.

Kelly chose William Shockley to lead the group. Shockley was brilliant, ambitious, and difficult — a theoretical physicist who combined genuine insight with a compulsive need for personal credit. He surrounded himself with people whose abilities complemented his own: John Bardeen, a quiet, methodical theorist from the University of Wisconsin who had a gift for understanding the quantum mechanics of surfaces, and Walter Brattain, a hands-on experimentalist who had spent his career probing the electrical behavior of semiconductor materials.

The three men were an unlikely team. Bardeen was self-effacing to the point of invisibility; colleagues sometimes forgot he was in the room until he spoke and said something brilliant. Brattain was a craftsman, more comfortable with a soldering iron than a blackboard. Shockley was the manager, the theorist, and — in his own accounting — the creative engine. He would eventually be proved, partly, wrong about that last part.

December 16, 1947

Through late 1947, Bardeen and Brattain worked together on a specific experimental approach: pressing metal point contacts against a germanium semiconductor surface and probing what happened when small voltages were applied. Shockley had predicted that a field applied above the surface would control current flow through the material. The experiments kept failing in ways that Shockley’s theory could not fully explain.

On December 15 and 16, 1947, Bardeen and Brattain made it work. Their device — two gold foil contacts pressed against a germanium crystal mounted on a metal plate — could amplify a signal. When a small current flowed through one contact, it controlled a much larger current through the other. They had created the point-contact transistor.

Shockley was not in the room. This fact would gnaw at him for years. He had led the group, defined the program, and provided theoretical direction — but the breakthrough had happened while he was elsewhere, and his name was not on the initial patent application.

His response was characteristically Shockley: within weeks, working alone in a hotel room in Chicago in January 1948, he developed the theory for an entirely new and superior device — the junction transistor, which replaced the fragile metal points with layers of differently doped semiconductor. The junction transistor was more reliable, more manufacturable, and more powerful than the point-contact version. It was the design that would actually be mass-produced.

The Announcement and Its Aftermath

Bell Labs management recognized the significance of the discovery but moved cautiously. The transistor was kept secret for six months while lawyers filed patents and engineers explored implications. On June 30, 1948, Bell Labs held a press conference to announce the invention. The New York Times covered it on page 46, a brief item in the radio news column. The world had not yet understood what had happened.

Bell Labs held licensing seminars throughout the early 1950s, charging a modest $25,000 fee to any company that wanted to learn transistor manufacturing technology. The policy was partly practical (Bell needed partners to develop manufacturing techniques) and partly mandated: AT&T’s regulated status made hoarding the technology legally awkward. The seminars seeded the transistor into dozens of companies across the United States and Japan. One of the attendees was from a small company then called Tokyo Tsushin Kogyo, led by Masaru Ibuka; it went home and built Japan’s first transistor radio (the TR-55, 1955) — a year after the American Regency TR-1 had become the world’s first commercial transistor radio. The company eventually became Sony.

The Nobel Prize and Three Men Who Couldn’t Speak

In 1956, Shockley, Bardeen, and Brattain were awarded the Nobel Prize in Physics “for their researches on semiconductors and their discovery of the transistor effect.” By the time the ceremony was held in Stockholm, the three men’s relationships had collapsed entirely.

Shockley’s behavior had become increasingly abrasive throughout the early 1950s. He took credit aggressively, excluded colleagues from key meetings, and managed through intimidation. Both Bardeen and Brattain had transferred to other Bell Labs departments specifically to avoid working with him. Bardeen, extraordinary man that he was, would go on to win a second Nobel Prize in 1972 for superconductivity theory — still the only person to have won the Nobel Physics Prize twice.

Shockley Semiconductor and the Traitorous Eight

In 1956, flush with the Nobel Prize and convinced he could run a company better than Bell Labs, Shockley moved back to his hometown of Palo Alto, California, and founded Shockley Semiconductor Laboratory — the first semiconductor company in what would eventually be called Silicon Valley. He assembled a team that was, by any measure, extraordinary: Robert Noyce, Gordon Moore, Jean Hoerni, Julius Blank, Eugene Kleiner, Jay Last, Victor Grinich, and Sheldon Roberts.

Shockley then proceeded to manage them exactly as he had managed at Bell Labs. He subjected employees to lie detector tests when a minor accident occurred. He announced salary information without consent. He redirected the company’s technical program away from silicon transistors toward a more exotic device that most of the engineers considered unpromising. He was, by all accounts of the people who worked for him, brilliant and impossible in equal measure.

In 1957, all eight engineers resigned simultaneously to found Fairchild Semiconductor with backing from Sherman Fairchild. Shockley called them the “Traitorous Eight,” a phrase he intended as condemnation that history has worn as a badge of honor. From Fairchild, Noyce and Kilby’s co-invention of the integrated circuit followed within two years. From Fairchild’s diaspora, Intel — founded by Noyce and Moore in 1968 — arose a decade later. See The Integrated Circuit Revolution and Gordon Moore and Moore’s Law for the sequels to this story.

Shockley’s company never produced a commercially successful product. He eventually left the semiconductor business and spent his later years promoting theories about race and intelligence that destroyed his scientific reputation. He died in 1989, estranged from his children.

Germanium to Silicon

The first transistors used germanium, the semiconductor material Bardeen and Brattain had experimented with. Germanium worked, but it had a fundamental weakness: it degraded at temperatures above about 75°C, which made it unsuitable for applications involving heat — including many of the military electronics applications that drove early transistor demand.

Silicon, the second most abundant element in the Earth’s crust, had better high-temperature properties but was much harder to purify and process. Through the early 1950s, researchers at Texas Instruments (where Gordon Teal had moved after leaving Bell Labs) and later at Fairchild developed the techniques needed to make silicon transistors practical.

Fairchild’s crucial contribution was the planar process, developed by Jean Hoerni in 1959: a method of building transistors by depositing thin layers on a flat silicon surface rather than cutting and dicing three-dimensional structures. The planar process made transistors manufacturable with photographic precision, enabling the yields and miniaturization that the integrated circuit required. Silicon became the universal substrate; germanium faded from the industry.

Why Everything Changed

The transistor’s advantages over the vacuum tube were not incremental — they were categorical:

Size: The first transistors were roughly the size of a peanut. Vacuum tubes were the size of a thumb. By the 1960s, transistors were being measured in micrometers. Today, transistors in a modern processor are measured in nanometers — roughly the width of a few silicon atoms.

Power consumption: A vacuum tube required continuous power to heat its filament. A transistor required power only when switching. A computer with transistors instead of tubes consumed a fraction of the energy.

Reliability: A vacuum tube’s filament would eventually burn out, just like a light bulb. A transistor with no heated filament had no comparable failure mechanism. Solid-state devices measured their mean time between failures in decades, not hours.

Cost and scalability: Vacuum tubes were hand-assembled glass objects, each one individually manufactured. Transistors could eventually be etched onto silicon wafers by the thousands, then millions, then billions — using photographic techniques that scaled cheaply.

Every integrated circuit is a collection of transistors. Every microprocessor is a collection of integrated circuits. The Intel 4004, introduced in 1971, contained 2,300 transistors. A modern Apple M-series chip contains over 100 billion. The device that Bardeen and Brattain demonstrated in Room 1E455 at Bell Labs on December 16, 1947, was not one invention among many. It was the invention that made all the others possible.
